دوربین FPV سونی 700TVL

کاتالوگ محصول

CCD type: "Sony 960H Exview HAD CCD II
Product Name: SONY 700 line
Shell Size: 28mm * 28mm, weight: 10 g
(total pixels: PAL: 1020H × 596V (61 million pixels) NTSC: 1020H × 508V (52 million pixels
(Effective pixels: PAL: 976H × 582V (57 million pixels) NTSC: 976H × 494V (48 million pixels
(Signal System: PAL / NTSC (default PAL system, NTSC system optional
Resolution (horizontal center): 700TVL
Digital Noise Reduction: 2D Digital Noise Reduction (2DNR) 0-15 16 support level can be adjusted Minimum illumination: 0.01LUX / F1.2 SNR: ≥48dB
Video output amplitude: 1.0Vp-p / 75Ω
AGC: 0.25 / 0.50 / 0.75 / 1.00 four levels can be adjusted to up to 55dB
White Balance: On / Off selectable
Backlight Compensation: High Brightness Backlight Compensation (HLC) / Backlight Compensation
Exposure mode: Electronic exposure
Electronic Shutter: 1/50 ( 1/60) - 100000 seconds
Gamma correction: 0.45 / 1.0
Synchronization: Internal synchronization
Lens: Lens Standard 2.8mm
Working voltage: DC12V (wide voltage, measured can 7.5-13V work )
Operating Current: 70mA (low power)
Operating temperature: -20 ℃ --60 ℃ Humidity: 0% to 98%
