Shape Memory metals  were developed by NASA for the space industry, and have been used for increasing applications down on earth.For example,there have been limited studies on using these materials in robotics. They make it possible to create very light robots.





The Dash4 memory metal actuator provides a stroke of 0.23" and over 1.75 pounds of actuation force. The built-in limit switch allows for safe operation over a wide range of voltage (thus, actuation speed) when used along with the MAD-v5 (sold separately). The Dash4 is just under an inch wide, and less than 0.1" thick!
  • Automotive
    • Bi-directional grill louver mechanism
    • Fuel tank door release mechanism
    • Trunk, glove compartment release mechanism
  • Consumer
    • Memory card ejector
    • Electronic latch release
    • Security doors and locks
    • Biometric sensor assist
  • Hobby/Miscellaneous
    • Grasping device
    • Undersea Core Sampling Robot
    • Point Of Use sale items
    • Latch release for ROVs
    • Pneumatic actuator replacement



  • Stroke: 0.23 inches(5.8mm)
  • Output Force: Constant 1.75 lb-f
  • Actuation Time: 50 ms to Position-Hold
  • 7V actuation: ~2.1 amps, 0.25 *
  • Resistance: 3.2 ohms*
  • Mounting: Holes for 2x 2-56 screws
  • Eletrical interface: 3P header on 0.1" pitch
  • Operating Temperature: -20~170°K (-29~60℃)
  • Size: 68x38x3mm (2.68x1.50x0.12")
  • Weight: 0.35 ounces (10g)



نظرات کاربران درباره Memory Metal Actuator - Dash4

نظری در مورد این محصول توسط کاربران ارسال نگردیده است.
اولین نفری باشید که در مورد Memory Metal Actuator - Dash4 نظر می دهد.

ارسال نظر درباره Memory Metal Actuator - Dash4

لطفا توجه داشته باشید که ایمیل شما منتشر نخواهد شد.

کد امنیتی *
captcha

برچسب های مرتبط با Memory Metal Actuator - Dash4

فلزهای حافظه دار کنترل شونده با ولتاژ Memory Metal Actuator Dash4
قیمت: 1,690,000 ریال
کد محصول MOT-IMEM-2
وضعیت موجودی نا موجود
