مبدل سریال TTL به اترنت / RJ45

مبدل سریال TTL به اترنت / RJ45

Description:

USR-K1 is the high performance-cost version of Super Port.It is an embedded serial networking module,whose function is to realize bidirectional transparent transmission between TTL and Ethernet.The amazing part of K1 lies in its Ethernet port integration design.You can apply K1 to your products to realize networking communication.User can directly process data interaction through network and device to realize remote data acquisition, remote control and management.
K1 is based on the design concept of "Simple,Reliable,Affordable".And it has the same kernel solution and parameters as USR-TCP232-T.

System Information:
Processor:ARM
Flash:32K byte

Ethernet:
Port:Number1
Interface:Standard8 pin RJ45
Rate:10/100 Mbps，MDI/MDIX,auto switch between cross and direct connection
Protection:2KV electromagnetism isolation
Network Protocol:IP，TCP，UDP，ARP，ICMP
Buffer:send： 2K bytes，receive： 1K bytes

Serial:
Port:Number1
InterfaceStandard:TTL: pin type 3.3V
Data Bits:5，6，7，8
Stop Bit:1，1.5，2
Check Bit:None，Even，Odd，Space，Mark
Baud Rate:TTL:110 bps ~ 921.6 Kbps
Flow Control:null
Buffer:receive: 800 bytes
RS-485 Pull-up and Pull-Down Resistor:null,reserved 485 send-receive control pin

Software:
Virtual Serial（USR-VCOM）:Windows 2000 or higher（32 bit/64 bit）
Configuration:computer set-up software,serial command,network command

Basic Parameter:
Size:33.02 x 19.01 x 19.15 (mm) (including clips)
Operating Temp:.-25 ~ 75°C
Storage Temp:.-40 ~ 85°C，5 ~ 95% RH (no condensation)
Input VoltageDC: 3.3V
Working Current:200mA（MAX）@ 3.3V
Power:<1W
