جریان و ولتاژ
ماژول ولتاژ جریان INA219 DC با خروجی I2C
Datasheet
Zero CJMCU-219 module is a drift with I2C interface, bi-directional current / power monitor integrated circuit (IC), and further expansion of the energy-saving electronic products TI camp. INA219 with the industry's highest accuracy and most compact size, not only to monitor the voltage drop across the shunt resistor, the sensing shunt supply voltage, while also calculating power. The device is available in a SOT23 package, available for digital current sensing small servers, laptops, power supply, battery management and automotive and telecommunications equipment, low-cost solutions.
ماژول ولت متر به همراه نمایشگر دیجیتال 0 تا 100 ولت DC
سون سگمنت قرمز رنگ
Description
Three wires digital voltmeter,0.28" LED display,mini size,with reversal protection.
Measure voltage range 0-100V, need DC4-30V external power supply.
ماژول نمایشگر دیجیتال ولتاژ و جریان 100V / 10A DC
Features:
Functional set voltage meter in one, measuring current power from the measuring circuit, does not require a separate power supply isolated power supply, easy to use.
Affordable only 10 a few dollars you can have a fully functional voltage meter.
33V Variable Precision representatives : measuring stalls below 10V voltage measurement resolution of 0.01V, 10V with a resolution of more than 0.1V
ماژول مانیتورینگ ظرفیت باتری LTC4150
Odometers are extremely useful for cars, they tell you how far you have gone, wouldn’t it be nice if you were able to have a device that does the same for electrical current? The LTC4150 SparkFun Coulomb Counter Breakout is here to be your odometer for current. If you are wondering: a coulomb is defind as, to put it simply, one amp for one second. This breakout is capable of constantly monitoring the current your sensor is using, is able to add it up, and will give you a pulse each time a given amount of amp-hours have been used. When used effectively and if you start with a full battery, you’ll always know exactly how much of it is left!
ماژول مانیتورینگ باتری MAX17043
LiPo batteries are a great way to power your projects. They’re small, lightweight, and pack a pretty good punch for their size. Unfortunately, even the best batteries eventually run low on power and when they do it’s often unexpected (and at the worst time). Don’t be caught by surprise next time your board suddenly powers-down! The SparkFun LiPo Fuel Gauge connects your battery to your project and uses a sophisticated algorithm to detect relative state of charge and direct A/D measurement of battery voltage. In other words, it tells your microcontroller how much ‘fuel’ is left in the tank. The LiPo Fuel Gauge communicates with your project over I2C and an alert pin also tells you when the charge has dropped below a certain percentage.
ماژول سنسور جریان 5 آمپر ACS712
Acs712elctr-30A محصول allegro توانايي اندازه گيري جريان هاي AC ويا DC تا 5 آمپر را دارا ميباشد. ولتاژ خروجي اين سنسور متناسب با جريان عبوري از آن بوده و اين رابطه كاملا خطي است .همچنين ورودي و خروجي اين سنسور از نظر الكتريكي كاملا از يكديگر ايزوله ميباشد. ولتاژ خروجي 66mv±4.5%/A ميباشد.
ماژول سنسور جریان 30 آمپر ACS712
Acs712elctr-30A محصول allegro توانايي اندازه گيري جريان هاي AC ويا DC تا 30 آمپر را دارا ميباشد. ولتاژ خروجي اين سنسور متناسب با جريان عبوري از آن بوده و اين رابطه كاملا خطي است . همچنين ورودي و خروجي اين سنسور از نظر الكتريكي كاملا از يكديگر ايزوله ميباشد. ولتاژ خروجي 66mv±4.5%/A ميباشد.
ماژول اندازی گیری ولتاژ ZMPT101B تا 250 ولت AC
Specifications:
on-board precision miniature voltage transformer
on-board high-precision op amp circuit, the signal for precise sampling and appropriate compensation function
the module can be measured within the 250V AC voltage corresponding to the output of the analog can be adjusted
PCB board size: 49.5 (mm) x19.4 (mm)
ماژول اندازی گیری جریان ZMCT103C تا 5 آمپر AC
Specifications:
on-board precision miniature current transformer
on-board high-precision op amp circuit, the signal for precise sampling and appropriate compensation function
the module can measure less than 5A AC current, corresponding to the output of the analog can be adjusted
PCB board size: 38 (mm) x18.5 (mm)
ماژول اندازه گیری ولتاژ
Module description:
This module is based on the principle of a resistor divider design, enabling the terminal interface input voltage reduced five times, Arduino analog input voltage up to 5V, then the input voltage voltage detection module can not be greater than 5V × 5 = 25V (3.3V if used system, the input voltage can not be greater than 3.3Vx5 = 16.5V). Because Arduino AVR chips used in 10 AD, so the analog resolution of this module is 0.00489V (5V / 1023), so the minimum voltage detection module detects input voltage is 0.00489V × 5 = 0.02445V.
SFE Analog Voltage Panel Meter - 0 to 5V
Description
• Comes in handy for measuring the output of sensors with 5V ranges
• Measures DC voltage from 0-5 volts with 2.5% accuracy
• Clear and easy to read scale and an adjustable dial
• Meter's Face: 45x45mm
• Mounting hole should be 38mm
• Overall depth: 35mm
SeeedStudio Non-Invasive AC Current Sensor (70A Max)
Description
- Non-invasive AC current sensor (70A max)
- Used for measuring alternating current
- Ferrite core material
SeeedStudio Non-Invasive AC Current Sensor (60A Max)
Description
- Non-invasive AC current sensor
- Input current: 0~60A AC
- Build-in sampling resistance (RL): 31Ω
- Dielectric strength: 1000V AC/1min 5mA
SeeedStudio Non-Invasive AC Current Sensor (5A Max)
Description
- Non-invasive AC current sensor (5A max)
- Used for measuring alternating current
- Ferrite core material
SeeedStudio Non-Invasive AC Current Sensor (50A Max)
Description
- Non-invasive AC current sensor (50A max)
- Used for measuring alternating current
- Ferrite core material
SeeedStudio Non-Invasive AC Current Sensor (30A Max)
Description
• Non-invasive AC current sensor (30A max)
• Output mode: Voltage/1V
• Opening size: 13mm x 13mm
• Leading wire: 1.5m
SeeedStudio Non-Invasive AC Current Sensor (25A Max)
Description
- Non-invasive AC current sensor (25A max)
- Used for measuring alternating current
- Ferrite core material
SeeedStudio Non-Invasive AC Current Sensor (20A Max)
Description
- Non-invasive AC current sensor (20A max)
- Used for measuring alternating current
- Ferrite core material
SeeedStudio Non-Invasive AC Current Sensor (15A Max)
Description
Non-invasive AC current sensor (15A max)
Used for measuring alternating current
Ferrite core material
The SeeedStudio Non-Invasive AC Current Sensor (15A Max) is a sensor used for measuring alternating current. It is particularly useful for measuring whole building electricity consumption (or generation for that matter). The split core type is particularly suitable for DIY use it can be clipped straight on to either the live or neutral wire coming into the building without having to do any high voltage electrical work
SeeedStudio Non-Invasive AC Current Sensor (10A Max)
Description
Non-invasive AC current sensor (10A max)
Used for measuring alternating current
Ferrite core material
The SeeedStudio Non-Invasive AC Current Sensor (10A Max) are sensors that are used for measuring alternating current. They are particularly useful for measuring whole building electricity consumption (or generation for that matter). The split core type is particularly suitable for DIY use it can be clipped straight on to either the live or neutral wire coming into the building without having to do any high voltage electrical work
SeeedStudio Non-Invasive AC Current Sensor (100A Max)
Description
• Non-invasive AC current sensor (100A max)
• Output mode: 0-50mA
• Opening size: 13mm x 13mm
• Leading wire: 1m
Pololu ±30A ACS714 Current Sensor
Description
• Current sense: 0.066 V/A
• Effect based linear current sensor
• logic voltage: 4.5 V - 5.5 V
• Supply current: 13 mA
• Two mounting holes on the logic side
Pololu 30A ACS715 Current Sensor
Description
• Simple carrier for Allegro's 30A ACS715 Hall effect-based linear current sensor
• Accepts unidirectional current input upto 30A
• Output sensitivity: 133 mV/A
• High accuracy and reliability
• Operating temperature: -40°C to 150°C
• Logic voltage: 4.5V - 5.5V
• 80kHz bandwith
سنسور ولتاژ LV25-P
این محصول یک سنسور ولتاژ از تولیدات شرکت LEM است. سنسور LV25-P برای اندازه گیری ولتاژهای DC، AC، ولتاژ های پالسی و ترکیبی مناسب است. قسمت اوليه این سنسور به صورت گالوانيك از ثانويه ایزوله شده. ولتاژ قابل اندازه گيري اين سنسور بين 10 تا 1500 ولت می باشد. خروجي سنسور به صورت جريان متناسب با ولتاژ اندازه گيري شده است.
اين سنسور براي اندازه گيري ولتاژ از روش محاسبه جريان استفاده مي كند. براي اندازه گيري يك ولتاژ لازم است جرياني متناسب با آن ولتاژ از طريق يك مقاومت خارجي منشعب شده و با قسمت اوليه سنسور سري شود. مقدار اهمي مقاومت خارجي متناسب با نياز توسط كاربر تعيين مي شود.
سنسور جریان۵۰ آمپر AT 50 B10 ساخت شرکت LEM
Current Sensor 50A 1 Channel Transformer w/Conditioning Bidirectional Module
سنسور جریان ۵۰۰ آمپر ساخت شرکت LEM مدل RT 500
SENSOR CURRENT XFMR 500A AC
سنسور جریان ۵۰۰ آمپر LF 510-S ساخت شرکت LEM
Current Sensor 500A 1 Channel Hall Effect, Closed Loop Bidirectional Module, Single Pass Through
LF 510-S
سنسور جریان ۲۰۰۰ آمپر ساخت شرکت LEM مدل RT 2000
SENSOR CURRENT XFMR 2000A AC
سنسور جریان ۱۵۰ آمپر HO 150-Sساخت شرکت LEM
SENSOR CURRENT HALL 150A AC/DC
سنسور جریان ۱۳۰ آمپر LA 130-P ساخت شرکت LEM
SENSOR CURRENT HALL 130A AC/DC
سنسور جریان ۱۰۰ آمپر HO 100-S ساخت شرکت LEM
SENSOR CURRENT HALL 100A AC/DC
سنسور جریان ۱۰۰ آمپر HASS 100-S ساخت شرکت LEM
SENSOR CURRENT HALL 100A AC/DC
سنسور جریان LTS25-NP
این محصول یک سنسور جریان از تولیدات شرکت LEM است. سنسور LTS25-NP برای اندازه گیری جریان های DC، AC، جریان های پالسی و جریان های ترکیبی مناسب می باشد. قسمت حسگر این سنسور از مسیر جریان ایزوله گردیده.
جريان نامي اين سنسور 25 آمپر است ولي مي تواند رنج 0 تا 80± آمپر را اندازه گيري كند. خروجي سنسور به صورت ولتاژ متناسب با جريان است.
سنسور جریان LA25-NP
این محصول یک سنسور جریان از تولیدات شرکت LEM است. سنسور LA25-NP برای اندازه گیری جریان های DC، AC، جریان های پالسی و جریان های ترکیبی مناسب است. قسمت حسگر این سنسور از مسیر جریان ایزوله گردیده.
جريان نامي اين سنسور 25 آمپر است ولي مي تواند رنج 0 تا 36± آمپر را اندازه گيري كند. خروجي سنسور به صورت جريان متناسب با جريان عبوري می باشد.
سنسور جریان LA200-P
این محصول یک سنسور جریان از تولیدات شرکت LEM است. سنسور LA200-P برای اندازه گیری جریان های DC، AC، جریان های پالسی و جریان های ترکیبی مناسب می باشد. قسمت حسگر این سنسور از مسیر جریان ایزوله گردیده.
جريان نامي اين سنسور 200 آمپر است ولي مي تواند از رنج 0 تا 300± آمپر را اندازه گيري كند. خروجي سنسور به صورت جريان متناسب با جريان عبوري است.
سنسور جریان LA100-P
این محصول یک سنسور جریان از تولیدات شرکت LEM است. سنسور LA100-P برای اندازه گیری جریان های DC، AC، جریان های پالسی و جریان های ترکیبی مناسب می باشد. قسمت حسگر این سنسور از مسیر جریان ایزوله است.
جريان نامي اين سنسور 100 آمپر است ولي مي تواند از رنج 0 تا 150± آمپر را اندازه گيري كند. خروجي سنسور به صورت جريان متناسب با جريان عبوري است.
سنسور جریان HASS 600-S
این محصول یک سنسور جریان از تولیدات شرکت LEM است. سنسور HAS600-S برای اندازه گیری جریان های DC، AC، جریان های پالسی و جریان های ترکیبی مناسب می باشد. قسمت حسگر این سنسور از مسیر جریان ایزوله گردیده.
جريان نامي اين سنسور 600 آمپر است ولي مي تواند رنج 0تا 900± آمپر را اندازه گيري كند.
خروجي سنسور به صورت جريان متناسب با جريان عبوري می باشد.
سنسور جریان HAS400-S
این محصول یک سنسور جریان از تولیدات شرکت LEM است. سنسور HAS400-Sبرای اندازه گیری جریان های DC، AC، جریان های پالسی و جریان های ترکیبی مناسب میباشد. قسمت حسگر این سنسور از مسیر جریان ایزوله است.
جريان نامي اين سنسور 400 آمپر است ولي مي تواند رنج 0 تا 900± آمپر را اندازه گيري كند.خروجي سنسور به صورت جريان متناسب با جريان عبوري است.
سنسور جریان HAS200-S
این محصول یک سنسور جریان از تولیدات شرکت LEM است. سنسور HAS200-S برای اندازه گیری جریان های DC، AC، جریان های پالسی و جریان های ترکیبی مناسب میباشد. قسمت حسگر این سنسور از مسیر جریان ایزوله گردیده است.
جريان نامي اين سنسور 200 آمپر است ولي مي تواند رنج 0 تا 600± آمپر، يعني تا 3 برابر جريان نامي را اندازه گيري كند. خروجي سنسور به صورت جريان متناسب با جريان عبوري است.
